8K-10K Tuggers



 Porta Pull Master series 8K and 10K Cable tuggers are sure to create an          industry, shake up with  power, performance, portability and free UPS delivery.

  Features:

  * 8-10K lbs Pulling Force from all directions
  * Planetary gear delivers smooth Power.
  * 30% more pulling force than competitors.
  * 3.5 HP Two Speed Motor and Gearbox.
  * Pulling Speed at Load 8,000 lbs-6 fpm
  * Pulling Speed at Load 10,000 lbs-4.5 fpm
  * Self-Contained  for 1 Person Operation
  * 2 inch thru 4 inch Adapters Included.
  * Extendable head for 15 feet of extra wire.
  * 20 A Milwaukee motor with gear reduction
* Includes foot switch & Force Gauge


FULL 2 YEAR WARRANTY on parts and labor.






  The Master series 8000 lb cable tugger:

   Wire Capacity for the 8K

   4 x 800 kcmil cables 600’ with 3-90 degree bends.
   4 x 750 kcmil cables 500’ with 4-90° bends.
   5 x 600 kcmil cables 500’ with 4-90° bends.

   The 8000 lb pullers is the most portable and
   affordable large capacity puller that we sell.

   The Master series 8000 lb Tugger $7495.00









  The Master series 10000 lb Tugger

    Wire Capacity for the 10K

     4 x 1000 kcmil cables 500 ft with 3-90° bends
     5 x 750  kcmil cables 600 ft with 4-90° bends.
     8 x 600  kcmil cables 500 ft with 3-90° bends.

    The 10,000 lb puller is the most versatile in its
    class for large cable pulling jobs.

    The Master series 10000 lb Tugger $7995.00
